Image Sensor
1/2.8" 2.4MP HQIS Pro Image Sensor
-
Minimum Illumination
Color(0.1Lux),White and Black (0.01Lux IR LED On)
-
Shutter Speed
1/50s(1/60s)-1/100,000s?Auto/Fixed?
-
White Balance
ATW/MWB
-
Lens
3.6mm
-
Gain Control (AGC)
Auto
-
S/N Ratio
≥55dB
-
Back Light Comp
Auto
-
Resolution
2.4MP
-
Frame Rate
30fps (60Hz) , 25fps (50Hz)
-
WDR
≥120dB
-
Gamma Correction
0.45
-
OSD
Support
-
IR
IR Range of 20 Mtr.
-
No. of IR LEDs
12pcs
-
Operating Temperature
-10°C~+55°C
-
Humidity
10% ~ 90%?humidity?, ≤95% RH no dew
-
Power Source
DC12V(+/-15%)
-
Power Consumption
1W MAX
-
Dimension
154.6mm x 60.8mm x 91.1mm
-
Weight
0.28Kg
-
Video Output
1.0Vp-p Composite Output (75Ω / BNC), HD-AHD(1080P)\ HD-TVI(1080P)\ HD-CVI(1080P)\ CVBS , CVI Default setting
-
ICR
Auto/ White and Black/ Color/ External control OSD adjustable
